BLF/Sofirn LT1 A2 Review (Update on the popular BLF Lantern)

BLF/Sofirn LT1 A2 Review (Update on the popular BLF Lantern)

Rather than a full review this week, I wanted to update everyone on the differences between the current BLF/Sofirn LT1 A2 and the original I have here in black. You really should go back and read or watch my original review for all of the various in’s and outs. Thanks to Sofirn for sending this to me. If I have any coupons or things I will post them in the description along with the links to my social media.



Watch this review on YouTube:

Follow me on Instagram: https://www.instagram.com/liquidretro/

Join the Facebook Page: https://www.facebook.com/LiquidretroReviews/

Follow me on TikTok: https://www.tiktok.com/@liquidretro1

Enjoy this review? Buy me a Coffee/Beer: https://www.buymeacoffee.com/Liquidretro



So what’s changed?

In short, Sofirn has made a few changes to the driver board to update a few shortcomings of the original LT1 and bring it into 2022.

The biggest change here is the UI. The light still is Anduril firmware, but this time it’s Anduril 2. I am not going to go into extensive detail about all the changes to this UI, that’s been well covered by others since it came out, but it’s generally a little easier to use as Andruil 2 ships in the simple mode which is all your basic functions, brightness, ramping vs stepped, tint shift etc. You do have to enable Advanced mode (10 click/hold) to get into the special modes that allow you to use candle mode and lightning mode. It works really well on the lantern if you haven’t tried it.



PCB

The Driver PCB has been changed in the A2 version. The original featured pogo pins that were easily accessed by just removing the head of the light, these were useful for firmware updates, etc. However, on A2 this has been eliminated, and now to do similar things you have to unscrew the screws holding it in and use a SOIC clip to make changes. I would show you this but I found my screws to be extremely tight and began to round out one of the screws so I just stopped.

Another change is that all 14 of the 7135 chips are enabled by default. On the previous version, you could easily bridge connections on these to customize the LT1 for maximum brightness (all chips enabled) or maximum efficiency with only 6 enabled. LED’s remain the same Samsung LH351D LED in 2700k and 5000k to give you maximum flexibility. Enabling all of the 7135 chips, is worth about 200 lumens difference according to Sofirn.

I did do a runtime test to compare the two, and the original lantern does hold out longer, likely due to the slightly lower output, It ran on its the lowest output forever, vs the A2 version did eventually shut off sooner. I didn’t measure lumens here since the lantern doesn’t fit or is really suited for my lumen tube.



The V2 ran using 100% warm output to 6:26:00, the V1 ran in the same settings out to 9:40:00. As you can see from the graph the V1 ran a lot longer but this long time was really at 1% or less of relative output. The difference more at 100% was 90 minutes different with the V1 running longer but as I mentioned at a somewhat higher output. So the name of the game would be to run the V2 at less than 100% output to match the V1’s runtime.



Powerbank Function

A heavily requested feature that’s welcome to see in the A2 version is that the lantern can act as a powerbank. With up to 4 x 18650 batteries inside, there is considerable power here to tap in an emergency situation. I used my discharge equipment and got out about 7301mWh discharge. It could

Charging seems to be faster here too. I charged it from where it shut off to full in 6:40:00 vs the original took 10:15:00 so a nice increase but still safe.

Another small change I noticed was that the LED button went from a moderate to low power orange on the original to bright green on the A2 version. It’s a bit too bright in my opinion but luckily you can turn this down in the firmware in advanced mode.



Accessories

While the light doesn’t ship really with any accessories I did want to mention this because I have put a few on mine that I plan to replicate here on my A2 version. First is the carrying case, it’s really a case for a JBL Bluetooth speaker but it fits perfectly on the LT1 and allows extra space for a charging cable and charger if you wish. The link to this case will be below. Sofirn now sells a similar version of their own too.

I have also bought a magnet that threads into the ¼ 20 threads. It’s rubber-coated and strong. It has the ability to hold up the light when placed on a slick surface horizontally. It’s a great addition in my opinion.



Lastly, I have 3D printed a shade, now this isn’t the best quality it was when I was really new to 3D printing and still learning. I should redo it now that I know a bit more. It’s nice if you’re going to be using it for a long time to keep the light out of your eyes, the bad thing is it’s not compact.



Final Thoughts

While not an essential upgrade, the changes made on the PCB with the addition of the powerbank feature, and Anduril 2 make for a light that’s easier to use for newer users and a great addition to the survival and camping aspects of the light with the powerbank feature.

The question of if it’s worth picking up another is hard to say, It’s still a heavy lantenr with a somewhat high center of gravity. I think you should have more than 1 if you are in an area prone to nasty weather or lose power frequently. If you can solder you can also pick up a PCB from Sofrin direct to upgrade your original LT1 too which can be a nice option too for some people. Overall a nice addition to the family.

If you haven’t seen my reviews of the original LT1 I would recommend you check that out after this video. I also reviewed the LT1S recently which is the short version, it’s a great lantern, and in the coming weeks, I will review the LT1 Mini so make sure you subscribe so you don’t miss that one.



Sales and Links

Black with $10 off Coupon on the page, Use code (107RGP70) for another 10% off https://amzn.to/3wBm76s

Green, Desert Tan, Orange https://amzn.to/3NtTHRv

Sofirn Direct (Save 15% with code OM2ELDVF) https://www.sofirnlight.com/products/sofirn-blf-lt1-anduril-2-rechargeable-lantern-super-long-working-time-with-power-bank-function-ship-from-usa?scm=spz.search&ssp=spz

Sofirn Direct (Save 15% with code OM2ELDVF) https://www.sofirnlight.com/products/sofirn-blf-lt1-rechargeable-lantern-with-power-bank-function-adjustable-color-temperature-long-working-time?scm=spz.search&ssp=spz



A2 Circuit Board https://www.sofirnlight.com/products/sofirn-lt1-driver-new-version?scm=spz.search&ssp=spz



XANAD Case https://amzn.to/2KABHqb

Sofirn Carrying Case https://www.sofirnlight.com/products/carry-case-for-blf-lt1-or-jbl-flip-4?scm=spz.search&ssp=spz



Link to the Magnet I have https://www.ebay.com/itm/373022347244

I think this one will also work https://amzn.to/3Gge9mC



Posted on

Sofirn SC31 Pro Review & Giveaway ($27, 2000 Lumens, USB-C, SST40, 18650)

Sofirn has a new low cost EDC 18650 light out with the SP31 Pro. It features an SST40 LED capable of 2000 lumens and available with 2 different tints and onboard USB-C charging for a very low price. Thanks to Sofirn for sending this to me and providing a discount to my viewers. I also have a SP31 Pro to giveaway so make sure you check out the description of this video and top comment on how to enter to win.



Watch this review on YouTube:

Follow me on Instagram: https://www.instagram.com/liquidretro/

Join the Facebook Page: https://www.facebook.com/LiquidretroReviews/

Enjoy this review? Buy me a Coffee/Beer: https://www.buymeacoffee.com/Liquidretro



Enter the Giveaway https://gleam.io/Xmkd9/sofirn-sc31-pro-5000k-kit-giveaway



Pickup the Sofirn SP31 Pro from Amazon. Don’t forget to click the Coupon code on the page for an additional discount too.

5000k Kit https://amzn.to/39JoSGf with Coupon DCNKLHS3

6500k Kit https://amzn.to/39yFJLC



Packaging

Sofirn won’t win any packaging contests but for lights that are sold online I don’t really give any bonus points for spending more in this area. It’s functional, generic, and does the job. With the light you get a Sofrin branded 3000mAh battery (Light only options exist), USB-A to USB-C Cables, lanyard, and spare orings, button cover, and USB port cover as well as a decent manual.



Construction

The SC31 Pro has nothing I can find wrong with it, it’s a budget light but all the edges are chamfered anodizing is consistent, and markings are good. Starting at the tail, it’s slightly recessed but still tail stands well, non magnetic. The lanyard attachment point is on the tail as well. Internally you have a single spring and what looks like room for a magnet if you wish.



Threads are square cut and nicely greased. The body tube has one pocket clip area milled into it, but the tube is reversible so it could go on the front or back. There is standard diamond knurling and it’s about average grip.

The front of the light is removable. Internally it has a pretty stiff spring and it should work with all non proprietary 18650 batteries. Externally there is a silicone button thats fairly flush, the button has some texture to it to help you find it, and 2 LED underneath that work as a locator, and battery status indicator when charging. Minimal milling on the sides for heat dissipation. The USB-C Charging port on the rear has a rounded cover with a large flat. Mine fits pretty well and is out of the way. The head itself has a minimal bezel with no crenulations. There is a reflective coated glass lens, smooth reflector and LED centering is good.



Size and Weight

The SC31 Pro is very similar in size and dimensions to the popular Wurkkos FC11. And for good reason, Sofirn is the parent company to both companies. I measured the SC31 Pro at 115.7mm in length, minimum diameter at 24mm, maximum diameter at 26.5mm. Weight with the battery and clip was 110g or 3.88oz. It’s IPX7 water rated.



Retention

The SC31 comes with a basic lanyard that attaches at the tail cap if you want. The pocket clip is decent but not as deep carry as I would like with 22mm of the light sticking up out of your pocket. It is a friction fit clip but fairly tight. If only this was a deeper carry clip it would be even better.



LED & Beam

The LED that’s being used here is the Luminus SST-40 LED. It’s available in both Cool white (6500k) and Neutral white, and I have the latter here in 5000k. It surprised me a little as mine has a bit oa a rosy tint, it’s nice despite being only 70 CRI. It has a smaller hot center, with a medium amount of spill. There are some some kind of ugly outer edges in the beam with reflections off the edge of the reflector and bezel. Maximum output is rated at 2000 lumens and with the ramping modes you can adjust it to anything you wish. The light does have PWM but it’s minimal and only visible with my oscilloscope. This is expected since its running Andruil.



Heat and Runtime

One thing that I have started doing is comparing my lights running Andruil as they come from the factory and then after thermal calibration. While I firmly believe that lights should come calibrated from the factory the reality is for the money here they don’t and that’s a shame because it’s worth doing. ZeroAir has a good writeup on this in his reviews, and I followed that and the difference in my lights were impressive. Turbo runtime went from 1:50 when uncalibrated to 3:05 after calibration, with peak of that being right at 2 minutes. So if you get this or any Andruil light it’s worth going through the calibration procedure. Output was also roughly 13% better during most of the duration too. This does effect overall runtime going from 7:05:00 uncalibrated to FL1 to 4:05:00 when calibrated to FL1 but this is a trade off I am willing to take for more output and a less aggressive thermal restraint. Max temp I saw when calibrated was 41C but this is my own setting and was at the 7 min mark.



UI

The Sofirn SP31 Pro here uses the Andriul firmware by Toykeeper. It’s standard Andruil but I did notice one difference at the top and bottom of the ramp I don’t get the blink like I do on say my FW3A, and most other Andruil lights. I like this. By default the light ships in ramping mode, there is a stepped mode too. Andruil is good but complex. It’s highly configurable (for example you can change the behavior of the backlight switch) so make sure to take some time to understand it fully.



Recharging

The Sofirn SC31 Pro has onboard USB-C charging. It supports USB-C to C charging cables as well as USB-C PD in my tests. It’s great to see a budget light support this. Total charge time of the included 3000mAh 18650 battery from LVP at 2.780V to full at 4.145V was 2:30:00 with the maximum charging rate just at 1.88V. I have no complaints here, and it’s great to see at budget prices.



Pro

  • My NW SST40 LED here in 5000k has a really nice tint with a rosy hue
  • Fantastic value for a complete kit
  • Andruil firmware is a love it or hate it thing, but it provides a lot of options for the enthusiast or budding flashaholic.



Cons

  • The pocket clip here is a small letdown, it’s not as deep carry as I would have hoped.
  • Non magnetic tail, although easy to modify to make magnetic.
  • Edges of the beam are a little ugly.



Conclusion

I am not ready to call this the Wurkkos FC11 killer since it’s an extremely similar light made by the same parent company but what I will call it is an extremely good value for a slightly more advanced light because it has Andruil UI. While I love the LH351D in my FC11 the tint here in the SC31 Pro is better in my opinion, slightly brighter, but you do lose the high CRI of the LH351D.



The Andruil UI is complex, and that may be a turn off for some new to the hobby, but for a noob there is muggle mode. Take some time and study the diagram to understand how it works and I think you will enjoy it. Build quality here is appropriate for the price, nothing is bad but it’s also not class leading. This is a great all around light for the money here and I have no hesitation recommending it, especially at the price Sofrin has offered to my viewers with the discount you can find in the description. About $25 at the time of filming.



Enter the Giveaway for the Sofirn SP31 Pro Kit (5000k) https://gleam.io/Xmkd9/sofirn-sp31-pro-5000k-kit-giveaway

Posted on

Jetbeam RRT01 Review 2020 Version (Rotary EDC, Nichia LED, High CRI, 950 Lumens)

Jetbeam has a new version of the RRT01 Raptor out for 2020. If you remember back to last summer I reviewed the 2019 version of the light and loved it. The 2020 version adds an Optional Nichia emitter and changes how the rotary ring and UI work as well as being more flexible with different battery versions. Thanks to JetBeam for sending this to me to look at and review.



Watch this review on YouTube:

**Follow me on Instagram: https://www.instagram.com/liquidretro/

Join the Facebook Page: https://www.facebook.com/LiquidretroReviews/



Versions

There are now 3 versions of the Jetbeam RRT01 that all share the same name. There is the original from about 8+ years ago, the 2019 version and now the 2020 version. Each having their own differences in performance, batteries, and LED. I do wish JetBeam would have added a V1, V2, V3 or used a different name with the light so it was easier for the consumers to tell the difference. The easiest way to tell the difference between the 2019 and 2020 is to look at the tail. The 2019 has a place for 3 tritium vials, whereas the 2020 has a button on the tail cap.



Packaging & Accessories

The packaging of the RRT01 is very Jetbeam, it’s a blue and black retail hanging package with all the details you need on the outside and side panels. As far as accessories, it depends on the version you get. My kit has the optional 2x extensions tubes that allow you to use 18500 and 18650 batteries in the light. In addition to this  it comes with a 1100mAh JetBeam branded 18350 battery with microUSB charging onboard, 3 extra  orings, an allan key, 2 extra screws for the clip (Not torx), and replacement rubber boot for the rear switch in gray. You also get a lanyard, manual, and other paperwork.



Construction

The light is made from aluminum and anodized a warmer light gray with the control bezel being a silver. It’s nice to see a different anodizing color here. Machining is very good. Starting at the tail, there is a bezel around the center mechanical on/off button. When the button is in the off state the light doesn’t tail stand super well, but when the light is on the button has retracted enough that it tail stands great, so really a pretty thoughtful design as it helps you find it when you want to turn the light on.

The body section of the light has knurling around it with 2 flats with the minimal labeling on each side. The light then grows to match the size of the head and control ring. Threads are wide, square cut and non anodized. By default the light will fit 18350’s and CR123A batteries which are great sizes for EDC but if you want more runtime you can insert one of the extensions and use a 18500 if you have them or add both if you want to use a 18650. Just remember to use a protected battery as this light doesn’t have LVP. When the extension are in place it’s a little less elegant I think and heavy in the head.



The rotary control ring has some areas milled into it to give grip. It has a detent on both ends of the control area. From 0 to 100% is about 160 degrees of rotation. There is no detent in the control ring for the 2020 version of the light. The ring moves quite easily, I would like to just touch more resistance. The rotary really allows you to dial in the exact amount of light you want very quickly.

The head has an aluminum bezel that’s mostly built into the light and not proud. It is not glued but you will need a tool to get it loose. The glass lens is double anti reflective coated and it has a deep reflector with a light orange peal.



Size & Weight

I measured the length at 91mm in it’s shortest configuration. Each extension adds 15mm to the overall length of the light. Maximum diameter on the head of the light is 26mm, and minimum diameter at the head is 24.5mm. The extensions are slightly larger in diameter coming in at 26.46mm vs the 26mm of the head of the light.

Weight in it’s shortest configuration with the included battery and clip is 114.6g. With a 30Q and the 3x extensions came in at 153.9g.



Comparisons

The most obvious comparison with the RRTR01 2020 is the 2019 version and the lights look very similar. The largest difference is that the 2019 version is shorter without the tail switch. The lens’s are a little different too, the 2020 lights lens has a light orange peel and is deeper and the bezel is smooth. The diameter of the head is slightly longer too. The extension tubes fit either light. When you put the extensions on the light looks a little funny to me, it seems longer and the proportions are just off a little. For an 18650 light it’s a little on the long side when compared to the FW3A.



Retention

The RRT01 like it’s predecessors are using the “standard” steel flame pattern clip meaning most aftermarket clips on the flashlight market should fit here. THe stock clip is a little longer than many at 61mm. The screw holes are hex head instead the more common torx.



In the pocket it carries reasonably well. The slotted tail bezel that’s around the tail button sticks up a little more then I want but does protect the button well from accidental activation. It’s still deep enough I consider it deep carry. I found the short length to be about perfect in the pocket, it’s doable to carry with the extensions on and an 18650 but it’s center of gravity is more to the head.



LED & Beamshots

There are 2 LED’s offered in the RRT01 Raptor (2020), a Cree XP G3 offering 80 CRI, and a Nichia 219C at 90CRI. I have the latter and it’s a nice warm 4000k. For me this is a great combination of tint and high CRI. JetBeam claims both are rated for 950 lumens, and that would be higher then I would expect out of a Nicha 219C as they typically don’t put out quite as much light as the Cree XP G3, so I take that with a grain of salt. It’s enough light to do the job easily. The beam here is nice for EDC, it has some center spot, about 20% of the beam and then fades to a useful spill. The rotary is very smooth and makes this light infinitely variable sub lumen up to 950. See the video version of this review for my Nightshots.



Heat and Runtime

Runtime here is very linear, I started my test with the included 1100mAh 18350 battery on full power. Output here was very linear and seems to not be regulated super well. There really isn’t much of a stepdown and the light ran above the 40% relative output out until 28 minutes. At 34 minutes the light shut off when LVP on the battery kicked in at 2.94V. The runtime here surprised me a bit, it’s rather short but then again this light doesn’t have much of a step down. It does get warm and the highest temp I saw was 59C around the 17 min mark.

I then tested with a 3000mAh 18650 battery. You need to use a protected battery with this light, I didn’t do that my first test and the result was the light ran until the cell was dangerously low right at 1V. I was not happy about ruining a battery here, but the result was significantly longer runtime. FL1 was at about 95 minutes, total runtime was just at 1 hour and 40 minutes. You can see thermal regulation kick in at the top end a bit.



UI

UI here is pretty unique to most other flashlights but it works pretty well. The RRT01 2020 version adds an on off switch at the tail of the light and combines with the rotary function in the head to change the brightness of the light. Once on rotate the ring to the right to increase in brightness, increase to the left to decrease in brightness. It is truly infantly variable as fast or as slow as you want. On my light I can turn the ring about 1/12 of the way before the LED begins to turn on.



This light does have an infinitely variable SOS and strobe modes as well. When on just rotate to to the maximum brightness setting and then to the left slightly 3 times and you get SOS, do this 4 times to get strobe. You can then dial back the brightness if you want. To exit just turn the light off and it goes back to normal.



Recharging

The light includes a 1100mAh Jetbeam branded 18350 battery that has onboard microUSB that you plug into the side of the battery. It has a multicolor LED on top that goes red when charging and green when charged. LVP is built into the battery and it stopped at 2.94V. Charged it stopped at 4.16V. When I plugged it in to charge I did notice the top of the cell got pretty warm, about 110F but this quickly dissipated. My guess is it’s doing this at first to gradually limit current going into the battery at the start of a charge. Overall the battery took 92 minutes to charge, and the maximum charge rate I saw was around the 70 minute mark at 1A. It’s a little odd to see that high of charge rate at the end of the charge cycle.



Pro’s

  • Nichia LED, my biggest complaint with the 2019 version of this light was the LED that was chosen.
  • I am a sucker for a rotary interface, it works here well but requires shifting your grip to turn on then adjust the output.
  • I like the anodizing color here, a warm gray, almost sand color.
  • Nice overall EDC light with options to go to 18650 too.



Con’s

  • No Low Voltage Protection, must use protected cells if you plan to run the battery to exhaustion,. .
  • A little awkward with the extensions installed, it throws the balance way forward.
  • Confusing naming with the previous versions of the light.
  • On the expensive side with the extension kit



Conclusion

The JetBeam RRT01 is the 3rd irrieteration of the light that shares the same name, while confusing for customers it’s a light I am enjoying. I really like rotary interfaces, I think they should be done on more flashlights as it’s intuitive and easy to operate for people of any age. The addition here of the on/off button on the tail instead of detents in the rotary makes the light less likely to come on in a pocket or when not in use but I think detracts from the overall rotary aspect of the light That said it still works pretty well but just requires you to change grips when using the light to turn it on and adjust the output.

The inclusion on some version with the extensions is smart, allowing you to use more battery types, it’s kind of an after though on design but it works reasonably well, especially if you want the extra runtime of an 18650, just be sure to use a protected battery since the light itself doesn’t have LVP.

The optional Nichia 219C emitter here is great. One of the features I liked least about the 2019 version was it was cool white and it’s great Jetbeam listed to this user feedback myself and others had. Overall this is a fun edc light, it’s a little on the expensive side but one I can still recommend. Make sure to check my links in the description as I will list any coupons or sales I get where you might be able to get a discount.

Banggood has a 30% off coupon for the 2020 version of the Jetbeam RRT01 at https://ban.ggood.vip/V8ca by using code:  BGRRLM



Posted on

Astrolux MF01 Mini (5500 Lumens, 7x SST20 LED, USB-C Recharging (Kind of))

Astrolux has gotten into the multiple LED flood and secondary LED’s with the MF01 Mini I have before me here. It’s available in 5 body colors, 3 material choices, and 3 LED tints with a high CRI option I have here. Thanks to Banggood for sending this to me and providing my viewers a discount. Make sure you check the description below if you are interested in this 5500 lumen light.



YouTube Version of this Review:

Get the Astrolux MF01 Mini at Banggood for $45.99 with Coupon code BGMF01Mini at http://bit.ly/340Nczj



Packaging & Accessories

Packaging is consistent with other recent Astrolux lights. A white box with minimal info on the outside other then the lights name and a silver line drawing of the light. Inside things are packed nicely with foam for protection. Accessories on this one include the light itself, A basic lanyard, and 2 adapter tubes for 21700 and 18650 batteries. No charging cable is included here which is disappointing considering this light requires USB-A to USB-C.



Construction

My MF01 Mini is made from Aluminium and has clear anodizing. They offer a variety of colors including black, olive green, a tan/gold, and gray. They also offer a special edition in Brass, copper and an aluminum copper combo. Machining is average, a few tool marks can be found on flat surfaces, they are smooth to touch and nothing wrong for a light in this price category.

The light tail stands well with the flat base, and the lanyard hole is at the base. Inside it has large stiff dual springs, this allows it to accept 26650, 21700, and 18650 batteries with the included adapters. Rattling was a small problem with the 18650’s but not an issue with the larger cells. The body tube has a crosshatch knurling patterning put on.

The head grows in diameter some, it has 4 gills milled in on either side for cooling. The switch is domed and sits prowd. It’s a silicone button and has texture on top. It has LED’s underneath to indicate charge status like other Astrolux lights. Opposite the button is the USB-C charge port. It’s covered by a silicon port cover and includes an area for the tab to sit. It’s out of the way no issues. The bezel on my light is aluminium however a stainless steel one is available for extra durability. There is a glass lens on top of the 7 LED optic. Underneath the optic you have the daughter board with the secondary LED’s. The light is IPX7 water rated, and I had no issues running it under a stream of water.

Size & Weight Comparison

This is primarily a 26650 light, but other similar sized batteries can be run. I measured length at 112mm, Minimum diameter on the body at 33mm, and maximum diameter on the head at 44mm. Weight with a 21700 battery installed was 254.6g.

The Fireflies E07 is a similar light also with 7 emitters and secondary LED. It’s smaller in diameter and lighter then the MF01 Mini, but the MF01 Mini does a better job of dissipating heat. That said the Mini can run 3 different battery types which is handy.



LED | Beam | Runtime

The MF01 Mini is using 7X SST20 LED’s. My example is using the 4000k tint, but 5000k and 6500k are also available. With the 4000k tint, the CRI is 95, less so on the cooler tints. The SST20’s have a bit of a reputation for having a bit of a green tint, especially at lower powers and that’s pretty apparent here. Andril firmware is great but it also means the LED’s can be driven very low and this is where the green comes out. At higher powers the tint is pleasing to me, it’s no Nichia 219 but not bad either. The beam is floody, with ever so slight hot spot in the center. For a floody light it throws decently well.

The light also has secondary LED’s in 3 colors, under the optic. Green on the outside, blue in the middle, and purple/pink in the center. These LED’s are on all the time the light has electrical contact.They are somewhat adjustable if you take the bezel and optic off there are 3 pots where you can adjust the brightness of each up to a point. There is a current limit so it’s better if 2 of the 3 are bright.

Runtime

I did my long duration runtime test with a Keeppower 5200mAh 26650 battery since that’s really what this light was originally designed for. It does fit 18650 batteries and 21700 with the included adapters. Total runtime here with this battery was just shy of 400 minutes. 99% of this time was at about 15% relative output.  Turbo output is good for under a minute on this light and it continues ramping down fairly quickly.

Heat on this light surprised me, I expected it to get quite hot based on other lights I have that are similar hot rods but that isn’t the case in my example and it’s a bit of a problem. So heat at 1 minute was 81F, at 5 minutes was 83F, and at 10 minutes 82F. The problem with this the light will start stepping down pretty quick. After I calibrate the light this should improve and allow the light to stay brighter for longer with the byproduct being heat. Low voltage protection kicked in at 3V.



UI

This light is using Toykeeper’s Anduril UI. It’s currently one of my favorites available as it has a ton of options and neat little easter eggs that commercial UI’s don’t include. By default the light comes in ramping UI which is where I left it. The ramping is fast and logical. A stepped mode is available that you can configure as well if you prefer.

The light has thermal controls, you can configure beacon mode, as well as 5 types of strobe including candle mode, party strobe, and lightning storm. You access these with 2 taps and a hold, and then two taps to change modes inside this group. Candle and lighting mode are my personal favorite. How practical these are could be a point where one could argue, but I like that they are present and it just makes things fun. Due to how you access these strobe modes I would not call the light a tactical UI or tactical light as you have to remember a series of presses and pauses to get there.



Personally I find the UI to be easy to use for what you want to do most often, but a little more complex to get to those modes you don’t use very often. This is a UI where you should take a look at the manual or at least the graphical manual for the UI and spend some time playing with your light to get the most out of it.



Recharging

This light has an onboard USB-C port for recharging, however it doesn’t support USB-C to USB-C cables, meaning you have to use a USB-A to C cable for recharging. For me this kind of defeats the purpose of having USB-C. Charging was reasonably fast, I charged my 5200mAh Keeppower 26650 battery in 3 hours and 30 minutes at a max rate of 1.85A. The battery stopped charging at 4.19V.



Pro’s

  • 5 colors, 3 tint’s available in Aluminum, Copper, Brass options are also available
  • High CRI (95)  available with the 4000k tint option
  • Versatile battery options with this light (21700, 26650, 18650 all work and the light includes spacer tubes



Con’s

  • Only support for USB-A to USB-C Charging. Doesn’t work for C to C.
  • With great power and lumens comes heat!
  • The SST20 LED’s in my example have a pretty green tint at lower outputs



Conclusion

Good competition for the Fireflies E07, Pretty good value at around the $60 mark normally or about $46 with my coupon in the description at the time of this video release. I enjoy secondaries on lights like this. They use minimal power and make them different from the competition. Overall a pretty good value light, hopefully Astrolux and other flashlight manufacturers will soon allow their USB-C lights to use C-C cables! Make sure if you decided to pick this one up, to take advantage of the color options here both in body color and tint. Let’s support one less black flashlight!



Get the Astrolux MF01 Mini at Banggood for $45.99 with Coupon code BGMF01Mini at http://bit.ly/340Nczj

Full image gallery can be found at https://imgur.com/a/AGU2g8L

Banggood is also having some other #BGBlackFriday sales you may be interested in below.



From Nov 27th – 30th

Black Friday:  http://bit.ly/2OnCmwJ

Saving Tips:  http://bit.ly/37cNPYB

Carve up $1,000,000 Bonus:  http://bit.ly/2rT3aNz

Home Garden Outdoor:  http://bit.ly/32TftGE



Groupbuy link:

XANES® 1282 XHP70: http://bit.ly/35czCZM

Amount: Need 20 persons

Groupbuy price: $14



XANES 1102 L2 5Modes: http://bit.ly/3415AYQ

Amount: Need 2 persons

Groupbuy price: $6.99



Posted on

Olight Baton Pro Review (2000 Lumens, 18650, EDC, Magnetic Recharging)

Olight has  new light on the market the Baton Pro. This is an update to the older S30R II and shares a lot of features with the S2R Baton II I looked at a few months ago. Thanks to SkyBen Trading for sending this to me to review. I will have a link to their shop in the description on where you can pick up this or any other Olight.



YouTube Version of this Review:

Purchase this light on Amazon: https://amzn.to/2NyAG35



Packaging

Olight has continued their white box theme of 2018 and 2019 and the Baton Pro is no different. It’s a white compact cardboard box, with a fold out top. On the front it shows the light, on the sides it gives a QR code and warranty time period (5 years). On the back it describes the light in pretty good detail and gives a runtime table.

The light is held in a white plastic holder, underneath are all the accessories held in place with a cardboard warning to remove the plastic protector to operate the light. Accessories for the Baton Pro include the customized (Proprietary) 3500mAh 18650 Olight battery, Blue pocket clip, Standard olight lanyard, Revised MCC II Charger, instructions and brown felt Olight bag.

Construction

If you have seen my review of the S2R Baton II you will notice a lot of the same design similarities on the Baton Pro. The light is made from aluminium and anodized a semi gloss black. Starting at the tail you will see the magnetic charging port. I did test the open contacts for safety with steel wool and didn’t have any issues. There is a magnet in the tail cap that is sufficiently strong to hold the light in a horizontal position on a painted steel surface. The tail also has a spot drilled in for the narrow included lanyard. The body tube and tail cap are all one piece. The bodies texture is a pyramid type design with the top milled off. It looks kind of like a corn cob. I like this new texture it provides quite a bit of grip but isn’t so aggressive it will tear up your hand or pocket.

The head here is different from the S2R II, it’s a bit longer at the top. This allows for a different optic, and some decorative milled circles. The side button has an LED in the center used for low battery indication. It’s a slicker plastic feeling button not a silicone button. It’s surrounded by a gloss blue ring, an Olight signature. The clip is removable but fixed in place. The only markings on the light are the Baton Pro are the Name and the serial number. Opposite this is the Olight logo.

The top of the light features a recessed blue Olight bezel. It’s a larger diameter as well as deeper then what was on the S2R Baton II, more similar to the S30R Baton II released a few years ago. On the top it’s engraved 2000 lumens and cool white. It features TIR style optic with a frosted center, clear cone and a flat glass lens on top.

Size & Weight and Comparisons

I measured the length of the Baton Pro at 108mm, maximum diameter at 25mm, minimum diameter at 23mm. Weight with the included battery and pocket clip was 110g.

Size wise the Baton Pro slots in the middle, it’s shorter then the S30R II with a narrower head, but not as short as the S2R II. Weight wise this makes it only 12 grams heavier then the S2R II, and within 1 gram of the S30R II.  While total output is a big jump up on the Baton Pro it’s more of an incremental change elsewhere.

LED/Beamshot/Runtime

Olight doesn’t specify the LED that’s being used in this light officially only that’s it’s cool white. It’s tint is cool white and pretty similar to the S2R Baton II that was using a SST-40. My guess would be it’s the same LED but I can’t be for sure. Not naming the LED is a shame for a light in this price category from a big player in the market. This gives them production flexibility but isn’t good news for enthusiasts.

The beam pattern with the optic has a hot center but alot more gradual spill then the TIR in the S2R Baton II. This new optic does seem to introduce some distortion mainly in tint it seems in the spill, where as the S2R Baton II is a harder cut off.

Officially output is listed at the following:

Turbo 2000 Lumens with step down to 600

High 600 Lumens

Medium 120 Lumens

Low 30 Lumens

Moon 5 Lumens



Mode spacing here on the normal modes excluding turbo is fairly even. It’s disappointing to see moonlight be so high at 5 lumens, to me this more like low not moonlight. The difference between high and turbo is pretty big. Now the interesting thing is it can sustain high (because it’s a lower output) for longer then average. Heat was well managed at the hottest it getting was 101F at the 5 minute mark.

Runtime

In Turbo the Baton Pro only lasts for 1 minute before stepping down 60% of relative output around 600 lumens, for around 15 minutes. At that point medium is the bulk of this lights runtime at 150 minutes before stepping down one more time for another 40 or so minutes. Total runtime is just shy of 200 minutes. Total runtime is pretty good for a single emitter 18650 but that time is well below the advertised max output and a large majority of its under 200 lumens, a bit disappointing in the output regard.

UI

The Baton Pro has the standard Olight UI many of us have come to know, and I like with the slower fades from off/on and between modes. From off, long press to activate moonlight mode at 5 lumens. To turn on in normal modes single click the switch, to change brightness level hold the button and the light will cycle through the 4 available modes lowest to highest. Double click to access turbo. Triple click to access strobe. The light also features memory mode for normal modes.



Lockout can be accomplished when the light is off by pressing and holding the switch for 2 seconds until moonlight mode comes on and immediately shuts off. If you then press the button the red LED under the power button will come on to let you know your in lockout mode. To exit lockout press the button for about 1 second until moonlight mode stays on. Personally I will just give the body of the light a ¼ turn to mechanically lock it out. The light features a short 3 minute timer, and a longer 9 minute timer. If these are setup (See the included manual) the light will automatically shut off when the end of the timer is reached.



Charging

The new MCC II charger is like we saw on the S2R Baton Ii. It’s edges are chamfered, and it’s still magnetic. It can now charge at 1A. Charging Time from a completely empty battery to charged was 4 hours and 41 minutes. Maximum charge rate I saw was 0.80A. . I would like to see a higher then 1A charge rate on their updated charger. That said this is very safe and conservative charge rate for the included 3500mAh battery. Full voltage was 4.185v.



Pro’s

  • I like the revised design and grip. Its an increase in texture but not too aggressive.
  • Good Basic, familiar UI
  • Useful beam pattern, not a pure flood or thrower.



Con’s

  • No Specific LED or Tint is officially mentioned here. This is very disappointing from Olight but gives them flexibility during manufacture.
  • Moonlight mode is quite bright at 5 Lumens
  • Proprietary battery is necessary for onboard recharging to work. The light does work with flat top with a magnet or a button top for just lighting.



Conclusion

The Baton Pro continues Olights small incremental updates of their lights in 2019. It would appear that the marketing department is pushing for those big lumen numbers rather then the R&D department coming out with bigger innovations or filling holes in the product line (Like a lantern or a Bike light).



That said this light has some good features, I like the texture on the body, the small speed improvement in the charging system. It puts out quite a bit of light for it’s size in a good quality beam pattern. It’s disappointing they don’t say exactly what LED is being used here or the tint, only that it’s cool white. Hopefully they won’t continue this practice for future lights. Overall it’s a bright compact light with a good 5 year warranty.

Posted on

Lumintop FW3A Review (Triple LED 18680 EDC light) BLF Designed

The Lumintop FW3A is a EDC style, small form factor triple LED flashlight that enthusiasts on the BLF forums designed and programmed during the past 2+ years. It takes design inspiration in several places from high end custom lights, and brings it down to an economical price. BLF was able to get Lumintop to agree to manufacture it and the rest is history. There have been a lot of reviews on the light so far, but here is mine. I purchased my original FW3A here in gray, but am thankful for Banggood for sending me the FW3C copper version of this light so that I can show it off and review it for my viewers.



Youtube Version of this Review:

Packaging

Packaging is nice at this price point. Lumintop designed a brown cardboard box with a line drawing of the light with a few specs on the outside. It has a slip cover and inside the lid folds out to reveal the light protected by cut foam with the paperwork on top. One of the important things that comes with this light is a little reminder to no open it from the tail side, and only open from the head side. This is because the tail assembly is where many of the difficult clearances are set and small parts are. More recent versions have added a retaining ring in the light which helps keep things together, but the best place to install a battery is by taking off only the head. Accessories are limited, with a couple of o’rings and the manual.



Construction

The switch in the light is a metal electronic switch in the tail and has very little travel but a positive click. This combined with the inner tube construction allows for the eswitch to work and give all the different functionality of the UI. That said it’s very important that the tail of this light is screwed down tight and not removed for reliable function. In my copper light there is now a retaining ring added which helps with this situation.

The body of the light is tapered, and this just makes it more ergonomic, it fits well in the hand and works better when clipped to pants or a bag. Threads are beefy, square cut and raw base material.

The head is two pieces, first on the outside you have the diamond knurled piece where the pill of the light and driver is and then you have the very top part where the Carclo 10511 semi clear optics sit. If you have a turbo glow gasket like I do in my copper FW3C here, it’s as simple to install as inserting it between the LED board and optic.

One final note on the construction of this light. The FW3 series of lights was designed with modders in mind. As a result, no glue was used in the construction of the light and that combined with a light at this price point made the light a little finicky. A good amount of people needed to troubleshoot their lights upon first getting them and as a result there is an extensive help thread over on the BudgetLightForums.



Personally I have been pretty lucky, my original gray aluminum light here was perfect out of the box and worked well, I did have a loose retaining ring in the head that I tightened down just to keep it working well into the future.



My Copper light here was a different story, it ended up having a slight problem with the location of the oring on the inner tube which made it not work reliably. After about 15 minutes of troubleshooting using the thread I will have a link to below I got it working again. It did have a design revision in the tail with the addition of a retaining ring to keep it from falling apart on removal. Most problems I have seen are usually fixable but there have also been some bad LED’s reported too.



Size | Weight | Carry

I measured overall length at 93mm, maximum diameter was 25.4mm and minimum diameter on the body at 21.5mm. Weight with the battery (VTC6) of the aluminum bodied light at 98.1g, and the copper FW3C with the same battery is 170.6g.



While watching this light develop over the 2+ years I was part of the vocal minority asking for a deep carry clip option. So far one hasn’t been made, but after carrying each light for a while I am not sure it really needs one. The clip is pressure fit between the tail and body of the light with an oring on either side. You can attach a lanyard on either the tip or top of it. It’s no secret that I don’t often EDC a 18650 light but with the FW3A it’s been a very pleasant light to carry in a front pocket. For me the shortness and small diameter combined with the taper on the body really make it a pleasant carry. While the copper adds weight I don’t notice that it’s too heavy and I like the way it looks.

LED | Beam Shots | Heat

The FW3A series of lights is available with a number of emitters. Banggood currently has 4 of them. 2 XPL-HI options at 5000k and 6500k, producing about 2800 lumens, and then a Nichia 219C at 4000k producing about 1600 lumens and a SST20 at 4000k a little under the XPL-HIs. The later two are 90+ CRI models. The Nichia is the least powerful of the bunch while the XPL-HI are the most output. Nielsgadgets also offers a XP-L Hi in warm white at 3300k. What I have here is a Warm White XPL-Hi in my Gray FW3A, and a SST20 in my Copper FW3C.  Thanks to that Carclo 10507 optic, the beam patterns for a triple is quite good, large hot center and fairly even spill. Throw is easily past 200 meters. Heat is considerable on this light especially on the higher outputs.



SST-20 Emitters at 4000k



XPL-HI at 3300K



Runtime

Runtimes and outputs on this light are basically what you should expect out of high performance hot rod like this with a limited amount of thermal mass. So in the normal UI you have high mode, and then a very limited “turbo”. Here is a graph that shows what 1 minute on Turbo looks like and we can see after 20 seconds it steps down ? of relative output,  Normal high mode starts to ramp down fairly quickly and stabilizes at about 9 minutes, but at a considerably less output. Long term the light sits about 40% relative output for well past 200 minutes. Overall runtime on this light is 100% thermally driven due to it’s mass and only having air to cool it.

The light does have low voltage protection onboard, so running unprotected batteries is fine and recommended for best performance here, but in my testing I couldn’t get find where exactly this kicks in at becaused the light runs quite low but never shut off in over 300 minutes.



UI

This light is using Toykeeper’s Anduril UI. It’s currently one of my favorites available as it has a ton of options and neat little Easter eggs that commercial UI’s don’t include. By default the light comes in ramping UI which is where I left it. The ramping is fast and logical. A stepped mode is a variable that you can configure as well if you prefer.

The light has thermal controls, you can configure beacon mode, as well as 5 types of strobe including candle mode, party strobe, and lightning storm. You access these with 2 taps and a hold, and then two taps to change modes inside this group. Candle and lighting mode are my personal favorite. How practical these are could be a point where one could argue, but I like that they are present and it just makes things fun. Due to how you access these strobe modes I would not call the light a tactical UI or tactical light as you have to remember a series of presses and pauses to get there.



For instance 4 clicks gives you lockout, and another 4 clicks unlocks the light, or you could just unscrew the head a tiny bit. If you activate momentary, the only way to clear it is to unscrew the head to do a full reset. 6 clicks from off gives you muggle mode which limits the lights output and output for a less complicated interface.



Personally I find the UI to be easy to use for what you want to do most often, but a little more complex to get to those modes you don’t use very often. This is a UI where you should take a look at the manual or at least the graphical manual for the UI and spend some time playing with your light to get the most out of it.



Firmware Flashing

Not all the FW3’s are coming with the latest version of firmware on them. It’s relatively easy to flash your own firmware if you want with only needing a computer, and inexpensive programmer. If this is something you would be interested in having me demonstrate on video, let me know in the comments below and I will add it to my list of future videos.



Mods

Lots of mods are available around this light. First and easiest are probably the Turboglow gaskets in a wide variety of colors, I have a lava colored one here in my Copper light and I quite like it, I think I will probably get a green or blue one for my aluminium version here soon. You can also get turbo glow to replace the tail switch, and a piece of sapphire glass for the lens, and tritium drilled optics. Since the light doesn’t have any glue an LED swap to something else is also pretty easy. Firmware is also flashable too, if you would like to see a video on how to flash firmware on the FW3A lights to make sure you have the latest version of Andril let me know in the comments below.

Pro’s

  • Nice value for what your getting with a wide variety of materials and colors to choose from.
  • While this started as just 1 line it’s spawned an entire family, with different LED choices, Material Choices, and soon a single emitter version, and a version that takes a 21700 battery for extended runtime.
  • Highly customizable, lots of emitter and material choices too.



Con’s

  • It’s a little bit of a fiddly light, for the BLF editions the decision was made to not glue anything for easier modding, the result is sometimes you have to just play with things a bit to get it to work reliably. I had this problem on my copper one, but not my original.
  • While I appreciate the small as possible size, that also means not a lot of thermal mass for heat dissipation and that means this light gets hot, from head to tail, pretty quickly on higher modes.



Conclusion

For me this is the enthusiasts light of 2019. It wasn’t a surprise since most of the development has happened on the forums in the open, but I don’t think anyone anticipated how popular this light would be and how it would spawn so many different versions. It’s really amazing that so many volunteers give their countless hours away to produce a flashlight for the community. Their hard work really shows through on this one. I have a couple different BLF designed lights and I don’t regret any of them. If you are a flashlight enthusiasts, collector, or EDC community member and you don’t have an FW3 series of light at this point, I would strongly encourage you to pick one up today, you won’t regret it.



Personally I don’t EDC a ton of 18650 light in my daily activities due to their typical larger size. That said the FW3 series of lights has been the exception. That tapered body makes a big difference in carry and so does the short overall length. While I would prefer a little deeper clip the included clip is pretty good. Modding capacity of this light is also very high, with people doing tons of things, and the aftermarket producing parts to add glow buttons, glow gaskets, drilled tritium optics, and more.



Below in the description I will have links to the different versions (Many colors of aluminium, Titanium, copper, etc) of the FW3 series of lights that Banggood is carrying currently as well as the TurboGlow gasket I have in my copper light here.



If you are a flashlight enthusiasts, collector, or EDC community member and you don’t have an FW3 light at this point, I would strongly encourage you to pick one up today, it might not be your one and only EDC light but it will be one to have a ton of fun with at an affordable price and will impress you for its abilities for the money and size. I recommend it!



Full Image Gallery on the FW3A: https://imgur.com/a/97Do9Mt



Pickup the Copper Lumintop FW3A From Banggood for $54.90 with Coupon Code BGLFCF2 at https://ban.ggood.vip/Ia5w



The Turboglow Gasket I am using can be found at https://ban.ggood.vip/Ia5u



Original Grey Edition: https://www.banggood.com/custlink/KKm36YwdNE

Blue Edition: https://www.banggood.com/custlink/3mvm6R7ysc

Olive Edition: https://www.banggood.com/custlink/3GK3BEThb5

Purple Edition: https://www.banggood.com/custlink/DDD3Bd1EQ8

Titanium Edition: https://www.banggood.com/custlink/Gm3K0EfYQ4

TurboGlow Button: https://www.banggood.com/custlink/DvDD6huEsA



Troubleshooting Thread:

http://budgetlightforum.com/node/66960



Useful Information on the FW3A lights and Troubleshooting:

http://budgetlightforum.com/node/67058



User Manual:

https://cdn.shopify.com/s/files/1/0031/0155/6806/files/Anduril_-_FW3A_user_manual.pdf?16

Posted on

Astrolux S43 (Quad Nichia LED, 18650/18350, USB Recharging, Hand Warmer Feature)

Astrolux has a small quad LED light, the S43. This builds on the the similar S41 and S42 line of lights. The S43 is a revised design, let’s see what’s good and bad about it. Thanks to Banggood for sending this to me to take a look at today.

Full Image Gallery: https://imgur.com/a/7w2r7Ym

YouTube Version of this Review: https://youtu.be/dq8lWspqUSY

Packaging

Packaging is pretty similar to other Astrolux lights of this size. It’s a brown paper box, with a bowtie cut in the middle almost. On the side is a sticker with the model and LED option on it. Inside the light is protected in foam. The S43 comes with lots of accessories that were once addon items in previous version. It now comes with a deep carry pocket clip, 18350 tube, lanyard, and glass breaker/skull cracker spike. It does come with a manual but it’s not quite accurate, it seems to be largely recycled from the S42.

View post on imgur.com
View post on imgur.com
View post on imgur.com

Construction

The head of the light has a non removable crenelated bezel that’s moderately aggressive. Underneath it has a small quad optic, similar to the S41. Below that the light has it’s button that glows green (Can be configured to turn off), surrounding the button is a copper/bronze colored bezel. The sides of the driver are a larger piece of milled aluminum with small heatsinks on the sides. Opposite the side button is the Micro USB charger port and cover. The port is fairly deeply recessed but I didn’t have a problem accessing it with a standard cable. The charger cover does have a tab that I seem to catch with my finger when the light is in use. It’s more annoying than functionally wrong.

View post on imgur.com
View post on imgur.com
View post on imgur.com

The body tube is fairly smooth with no knurling ot texture for grip which is unfortunate.. There are indents at either side for the clip. The tubes are not reversible. It looks very similar to the battery tube on my Emissar D4. The S43 also comes with a 18350 tube which is nice that it’s not an additional purchase. The shorter tube is the same just shorter. It also has areas for the clip to connect. Threads are acme cut, and there is no spring in the head. This causes a bit of a problem if the light is jolted as it loses connection and doesn’t come back on by default.

View post on imgur.com
View post on imgur.com
View post on imgur.com
View post on imgur.com

Glass Breaker/Skull Cracker Spike. The tailcap of the light has as an optional (included) steel spike that can be screwed onto back of the light. For me this is more of a gimmick than useful. Yes it could be used a a self defense option, or used to break glass but the last thing I want is this spike sticking out of my pocket or poking a hole in my bag. Thankfully it can be removed and the threaded hole could be used to connect to a tripod. Personally I would get more use out of this if it was a magnet instead. The spike screws into a ¼ 20 insert. The insert can be removed and I am guessing it’s roughly a ? screw but I ma not quite sure. With the insert screwed in it doesn’t tail stand very stably.

View post on imgur.com
View post on imgur.com

Other versions of this light are also available. There is a version where the head portion is copper, and a red/green anodized version for the holidays. There isn’t a stainless steel model yet but I wouldn’t be surprised if we see one eventually.

Size/Weight

I measured length at 122mm without the spike or threaded adapter with the 18650 tube. Maximum diameter is 30mm at the head, and minimum diameter is 24mm on the body tube. Weight with battery and clip is 141.5G

View post on imgur.com
View post on imgur.com
View post on imgur.com
View post on imgur.com

LED/Runtime

The light comes with 2 versions, a cool white Cree XP-G3 LED and a Neutral white Nichia 219C at 5000k which is what I have. Tint on mine seems a little warmer than 5000k but I don’t mind. The light is capable 2100 lumens on it’s turbo mode.

View post on imgur.com

Beam shots has a warm hot spot in the center that a gradual fade as you move from the center. For a quad light it’s fairly round. At short distances you notice a few artifacts but these mostly fade away at 4-5 feet.

View post on imgur.com

Output & Runtime

The S43’s runtime and heat output is a little disappointing but roughly what I would expect from a small diameter quad Nichia light. So the light is capable of a maximum of 2100 lumens and has a ramping UI as it’s primary UI. I did my testing with a Sony VTC6. In turbo the light ran for just slightly over 1 minute before starting it’s stepdown. At the 1 minute mark I measured 113F at it’s hottest point. That is pretty warm very quickly. Between 1 and 2 minutes the light stepped down twice to about 10% relative output. This is a very big decrease in output really quickly. At 2.5 minutes the light reaches it’s comfortable longer term output at about 5-8% relative output. After 6 minutes I measured the light was 95F. It held this low output out to 375 minutes where the light stepped down a few more times to run at bear minimums. I stopped my runtime test at a little over 500 minutes. Overall I felt like while this light gets bright it’s almost unusable because of how fast the light steps down and how much it steps down. At least with it’s ramping UI you can adjust the output to exactly where you want it. Performance with a quality 18350 should be similar just with a shorter overall runtime. The light does have Low Voltage Protection which is good since you want to run it with a unprotected cell for the most output.

View post on imgur.com
View post on imgur.com

UI

This light has one single side switch (A change from the S41), and uses NarsilM ramping firmware for it’s UI. By default it comes with the Ramping enabled but there is a stepped mode if you prefer. For my testing I left it in the default ramping UI. Ramping is fast taking just under 2 seconds to go from the lowest to highest mode. It gives a brief flash at the top to let you know your there, and does it at the bottom too, although thats hard to see at such a low output. I will like to the manual in the description so you can look at the other options, it looks a little complicated to adjust but after you have done it a few times it’s not too bad.

Link to Mode 1 Manual

Link to Mode 2 Manual

Recharging

The light does have onboard recharging via MicroUSB. I measured the speed at 0.72A and this resulted in my 3000mAh Sony VTC6 taking 5 hours and 2 minutes to charge to completely full. A little slow for an 18650 but a very safe speed especially if your using it with a 18350.

View post on imgur.com

Pro’s

  • I like that it now comes with the 18350 tube and a pocket clip for the price. (They used to be add on items)
  • Nichia LED option
  • NarsilM Firmware (Ramping UI with lots of configurable options)

Con’s

  • Step downs from Turbo are large and the light gets beyond warm
  • Breaks connection (Light turns off) if using flat tops and the light is jolted (Doesn’t come back on)
  • Smooth body

Conclusion

For the price this is one of the least expensive Quad LED lights you can get usually (when on sale, see youtube for a coupon). For its size it puts out a ton of light, but at least in this S43 the step down from Turbo to high is quite large and it gets hot! Turbo is more of a momentary because it lasts so little time. I wish it had a bit more grip and didn’t lose connection if jolted hard (Like if using the glass breaker), especially for a light that advertises itself with tactical features.

Posted on

Xtar X2 Dual Bay Smart Quick Charger Review

Xtar has a new charger on the market the X2 and X4. Today I have a review of the X2, a 2 bay 2A charger capable of charging Li-ion and Ni-MH batteries, with AC or USB Power. Thanks to Xtar for sending this to me to test and review.

Full Image Gallery: https://imgur.com/a/T2ewQ1Z

YouTube Version of this Review: https://youtu.be/MXD3-AGlmew

Packaging

The packaging is a white retail box with a gloss photo of the X2 on the front. The sides list a few key features such as the charging speed, Inputs, LCD display, the chemistries and sizes of batteries that are supported. The back gives more specifications and features of the charger. It contains a scratch off anti counterfeit sticker and is insured worldwide. The package contains the charger, AC power cable, and the manual.

View post on imgur.com
View post on imgur.com
View post on imgur.com
View post on imgur.com
View post on imgur.com

Construction

The Xtar X2 charger is a 2 bay charger that can accommodate most common battery sizes. I had no trouble with all 18650’s, it will fit 2x 26650, and I didn’t have any issues with an unprotected 20700. Smaller batteries were ok too, 18350, AAA, etc. It will not charge a protected 21700 battery. The metal sliders are fairly smooth and have enough tension on them to hold a battery securely.

View post on imgur.com
View post on imgur.com

The body of the charger is a black ABS plastic that is heat and flame retardant, and is kind of in an X configuration, in outside appearance. There isn’t a fan in this charger meaning it’s silent, and I didn’t notice it get warm during use. There is one button on the top, middle near the screen that when held turns the screen off, for night time charging if you wish.

View post on imgur.com
View post on imgur.com

I took some photos of the inside of the charger here. I am not a circuit engineer but to me it looks decent. Quality of the solder joints look good, A few components are not 100% squarely placed but not bad either. I don’t see any cold joints or things that I am alarmed about. If you see something you are concerned about, make sure to leave a comment.

View post on imgur.com
View post on imgur.com
View post on imgur.com
View post on imgur.com
View post on imgur.com
View post on imgur.com

Screen

The screen is a LCD with a dark black background and white text that’s tinted blue with a blue backlight. On each bay you get a 0-100% indicator showing what percentage the battery is at, on the top right corner you get the current voltage, below that you get the charge rate, below that in the center you get the mAh that’s been put into the cell since the start of charging, and lastly on the bottom left hand corner you get the cell chemistry that’s been detected. The screen is easy to read and I had no complaints about it. It does time out after a few minutes, you can press the button to wake it up.

View post on imgur.com
View post on imgur.com

Performance

My main charger for a while has been an Xtar VC4 which I really like, but the problem with it is it’s USB only input power, sometimes if charging performance isn’t what I expect I end up doing the dance of “is it the USB power supply? Or the wire, or something else?” The X2 solves that because it’s a part of Xtar’s AC series, meaning it plugs directly into the wall. You can also power it via MicroUSB if you prefer. For my tests I used the AC power source.

The charger has reverse polarity detection and didn’t charge batteries when they were placed in backwards. Battery chemistry was correctly identified, when you place a new cell in it takes a few seconds for it to go through detection and begin charging.

The charger is capable of a maximum of 2A across both bays. The left bay is capable of up to 2A under the correct conditions, and the right bay is capable of up to 1A under the correct conditions. If there is only 1 battery in the left bay and it’s a lithium ion type chemistry it will charge at 2A. If you have 2 Lithium cells they will each charge at 1A. The charger does a great job of recognizing the type of cell, my smaller 18350’s despite being lithium will charge at a slower 0.5A rate which is great for battery longevity. It detects this all on it’s own and it does this in either bay. You can also mix chemistries across the charger, 1 18650 for example in the left bay and one AA NiHM in the right, it will charge the 18650 at 1.0A and the NiHM at 0.5A.

While slower charging is safer, I would like to see the charger capable of a combined 4A across each bay, for faster charging of large batteries like 26650 and 20700’s etc.

The charger has 0V activation (Although this is generally not recommended for batteries with a Lithium chemistry). For charging it has a 3 step process TC-CC-CV with soft start technology. This helps with overall battery longevity and long term health.

Pro’s

  • All automatic, this make the charger very easy to use but doesn’t give enthusiasts any options on what speed to charge the batteries at. Default settings are conservative, which is safe.
  • AC Power via a fairly standard cable. The charger is compatible with 120/240v so it’s safe for international use. It can also be powered via MicroUSB.
  • Very affordable, at US retailers it’s coming in well under $20.

Con’s

  • Only a combined total of 2A charging speed, while adequate, I would like to see it able to charge 2A per bay in 2019 if connected via AC.
  • I would like to see the USB input be in USB-C over MicroUSB because it’s 2019.

Conclusion

The Xtar X2 is my current favorite 2 bay charger. I really like that it’s got dual input including AC, which makes it versatile to use whatever power source is best for you in your situation. It takes a wide variety of sizes of batteries, and the most common chemistries as well. Xtar has a good reputation around the Flashlight and Vape communities for making quality chargers at affordable prices. The X2 is no different, and continues this trend. Xtar also makes the X4 version of this charger if you want 4 bays. It offers a little faster charging depending on where you put batteries and isn’t much more expensive. Either charger would be great for anyone who is just getting into flashlights or if your just looking to upgrade to a newer/faster charger. I recommend it.
